Friend of mine has a Z1r which he has owned since nearly new and he is having constant problems with the wiring. Does anyone know if a replica is available (like the Z1 ones)?

compo z1r · #2 PostAuthor: **compo z1r** » Sat Jun 02, 2012 9:08 pm

coldsummer wrote:Friend of mine has a Z1r which he has owned since nearly new and he is having constant problems with the wiring. Does anyone know if a replica is available (like the Z1 ones)?

no not as yet simon i know some have had some made up from scratch
and depends on whats wrong ive got a spare he can have to make good if wanted and some of the connector blocks are available :wink:

000zeds · #3 PostAuthor: **000zeds** » Sat Jun 02, 2012 9:34 pm

Z-Power have looms to suit Z1000 are the Z1R ones much different :?:

compo z1r · #4 PostAuthor: **compo z1r** » Sat Jun 02, 2012 9:36 pm

twozeds wrote:Z-Power have looms to suit Z1000 are the Z1R ones much different

yes a1-a2 do not fit

coldsummer · #5 PostAuthor: **coldsummer** » Sat Jun 02, 2012 9:46 pm

Thank compo, I thought that was the case as I couldn't see any on the Z-power site (although that doesn't always mean anything). I think it has been repaired many times over the years and the connectors are all a bit brittle. He's coming down to Bristol soon so hopefully I'll catch up with him and find out a bit more about the issues. Thanks for the kind offer of your spare loom, I'll let you know if he needs it. Cheers.

z1bman · #6 PostAuthor: **z1bman** » Sat Jun 02, 2012 9:50 pm

dont know if this is of any use ?

http://www.z-fever.de/ShopNeu/shop/show ... ts_id=1000

coldsummer · #7 PostAuthor: **coldsummer** » Sat Jun 02, 2012 9:55 pm

z1bman wrote:dont know if this is of any use ?

http://www.z-fever.de/ShopNeu/shop/show ... ts_id=1000

That's interesting, not sure if MKII is same as Z1R though? Pretty sure it could be adapted by someone with a bit of wiring know-how.

compo z1r · #8 PostAuthor: **compo z1r** » Sat Jun 02, 2012 10:08 pm

coldsummer wrote:
z1bman wrote:dont know if this is of any use ?

http://www.z-fever.de/ShopNeu/shop/show ... ts_id=1000

That's interesting, not sure if MKII is same as Z1R though? Pretty sure it could be adapted by someone with a bit of wiring know-how.

due to the z1r fairing it will need to be adapted to the clock loom which is z1r only :wink:

for starters

compo z1r · #9 PostAuthor: **compo z1r** » Sat Jun 02, 2012 10:14 pm

z1bman wrote:dont know if this is of any use ?

http://www.z-fever.de/ShopNeu/shop/show ... ts_id=1000

just had a good look a lot different to z1r :roll:

HowieD · #10 PostAuthor: **HowieD** » Sun Jun 03, 2012 5:53 pm

Hi,

I used to have quite regular wiring things happening with my Z1-R. I made a complete new one (several times) with all the wire & connectors from here:

http://www.vehicle-wiring-products.eu

All you need is the original one as a pattern and the colour diagram from the manual. I found it better to build the loom actually on the bike too.

The latest reincarnation of mine uses waterproof mini connectors.

Hope that is some help

H

coldsummer · #11 PostAuthor: **coldsummer** » Sun Jun 03, 2012 7:07 pm

HowieD wrote:Hi,

I used to have quite regular wiring things happening with my Z1-R. I made a complete new one (several times) with all the wire & connectors from here:

http://www.vehicle-wiring-products.eu

All you need is the original one as a pattern and the colour diagram from the manual. I found it better to build the loom actually on the bike too.

The latest reincarnation of mine uses waterproof mini connectors.

Hope that is some help

H

Thanks Howie, that is an option although not as easy as buying a repro :wink:

gray · #12 PostAuthor: **gray** » Sun Jun 03, 2012 7:57 pm

Does Dave Ennis still recondition looms? he did mine a million years and 50,000 miles ago and it's still going strong, it was all horrible and scotchblocked and everything
